Incredible STRAPS - TX
DY incredible STRAPS - TX
- We have been manufacturing SPECIAL PET Strapping which is mainly used as compatible substitute for Signode TENAX. The TX strap range can be safely used on Signode automatic packaging machines without any modifications to the machine.
- The specifications of the DY incredible STRAPS - TX are almost identical to the DY Incredible STRAP HD range except for the strap surface/finishing which are special in order to travel well through the machine feed wheel.
Features
Raw material Quality Control
Weld strength: above 90%(ASTM standard : 75%)
Highest remaining holding force
Splitting resistance
Strict tolerance of size: Fully automatic line use
Perfect shock elasticity
Better productivity: low dropout rate
100% Made in Korea with European facility
Technical Specifications
| Width | Thickness | Tensile Strength(KGF) | CORE (mm) | Elongation (%) | |||
|---|---|---|---|---|---|---|---|
| mm | inch | mm | inch | kfg | LBS | ||
| 12.70 | 1/2 | 0.71 | 0.028 | 360 | 794 | 406 | 14±2 |
| 15.60 | 3/5 | 0.76 | 0.030 | 500 | 1,102 | 406 | 14±2 |
| 15.90 | 5/8 | 0.90 | 0.035 | 630 | 1,389 | 406 | 14±2 |
| 15.90 | 5/8 | 1.00 | 0.040 | 680 | 1,499 | 406 | 14±2 |
| 19.00 | 3/4 | 0.90 | 0.035 | 750 | 1,653 | 406 | 14±2 |
| 19.00 | 3/4 | 1.00 | 0.040 | 830 | 1,830 | 406 | 14±2 |
| 19.00 | 3/4 | 1.27 | 0.050 | 1,060 | 2,337 | 406 | 14±2 |
| 25.00 | 1 | 1.00 | 0.040 | 1,100 | 2,425 | 406 | 14±2 |
| GREEN IS STANDARD COLOR; OTHER COLORS AVAILABLE UPON REQUEST | |||||||
| STANDARD NET WEIGHT IS 20KG PER A COIL; OTHER COIL WEIGHTS AVAILABLE UPON REQUEST | |||||||
Your advantages are
No damage/stainson product
Color doesn't seep into product
Safety
Safe bale opening, smooth edge
Eco-friendly
100% recycleable, low CO2 emission
Saving Storage cost
No rust, UV resistance, hot and humid weather resistance.
Saving Transportation Cost
Light weight
Saving Packaging Cost
