Incredible STRAP HD

DY Incredible STRAP HD provides the perfect solution for heavy goods.
Incredible STRAP HD is manufacturedwith quality raw material which are subject to strict quality control testing.
This strap was developed according to market demand as part of an effort to reduce packaging cost.
This strap is increasingly popular as a substitute for steel strapping which is used for baling, palletizing, bundling, carton closure and unitizing applications.

Raw material Quality Control

Weld strength: above 90%(ASTM standard : 75%)

Highest remaining holding force

Splitting resistance

Strict tolerance of size: Fully automatic line use

Perfect shock elasticity

Better productivity: low dropout rate

100% Made in Korea with European facility

Width		Thickness		Tensile Strength(KGF)		CORE (mm)	Elongation (%)
mm	inch	mm	inch	kfg	LBS	CORE (mm)	Elongation (%)
9.00	1/3	0.50	0.020	190	419	406	14±2
10.50	2/5	0.68	0.027	300	661	406	14±2
11.50	4/9	0.52	0.020	250	551	406	14±2
12.00	1/2	0.50	0.020	260	573	406	14±2
12.00	1/2	0.60	0.024	315	694	406	14±2
14.00	5/9	0.60	0.024	370	816	406	14±2
15.90	5/8	0.90	0.035	630	1.389	406	14±2
15.90	5/8	1.00	0.040	700	1.543	406	14±2
19.00	3/4	1.00	0.040	835	1.841	406	14±2
19.00	3/4	1.27	0.050	1,060	2.337	406	14±2
25.00	1	1.00	0.040	1.100	2.425	406	14±2
25.00	1	1.27	0.050	1,350	2.976	406	14±2
32.00	1, 1/4	0.80	0.030	1,130	2.491	406	14±2
GREEN IS STANDARD COLOR; OTHER COLORS AVAILABLE UPON REQUEST
STANDARD NET WEIGHT IS 20KG PER A COIL; OTHER COIL WEIGHTS AVAILABLE UPON REQUEST
